Puch engine & gearbox

swiing® revival plain bearing clutch basket | Puch Z50

Ø inside: 15 mm · Nominal diameter inside: 15 mm · Ø outside: 17 mm · Total height: 16.2 mm · Manufacturer: swiing® revival parts · Material: special bearing bronze

Rubber kickstarter original | Puch

Material: Rubber

GPO 38 mm gasket cylinder head 0.4 mm aluminum | Puch

Manufacturer: GPO · Material: Aluminum · Place of use: Cylinder head · Thickness: 0.4 mm · Nominal diameter: 39 mm · Ø inside: 39 mm · Ø cylinder: 38 mm · Ø screw holder: 7 mm · Hole pattern [mm]: 44 x 44 · Area of application: Standard · Puch OEM number: 349.3.10.013.1

swiing® revival gearbox cover gasket (new model) | Puch Z50 engine

Manufacturer: swiing® revival parts · Material: Sealing paper · Color: sand-colored · Number of components: 1 pcs · Total length: 170 mm · Width: 120 mm · Thickness: 0.35 mm · Number of fixing points: 7 pcs

Jasil crankshaft full cheeks (new model) | Puch E50

Manufacturer: Jasil · Material: Steel · Cheek type: Full cheeks · Crankshaft stroke: 43 mm · Connecting rod length center-center: 90 mm · Total length of crankpin on clutch side: 74 mm · Total length crankpin ignition side: 67 mm · Ø crank webs: 69.9 mm · Ø piston pin (B): 12 mm · Ø Connecting rod eye: 15 mm · Ø Bearing seat (clutch side): 17 mm · Ø Bearing seat (ignition side): 17 mm · Thread type: MF10x1 (fine pitch thread) · Thread length: 10 mm · Thread length: 13.5 mm · Dimension needle bearing: 12 / 15 x 14.7 mm (axe 12) · Wide crank webs: 34.3 mm · Length 1st paragraph: 23.3 mm · Length 2nd paragraph: 25 mm · Ø 1st step (on the coupling side): 17 mm · Ø 2nd shoulder (on the clutch side): 15 mm · Length of shoulder (ignition side): 26.3 mm · Weight: 964 g · Number of gears: 1 pcs · Area of application: Racing

Shaft seal NBR 16/25/7 A Kickstarter | Puch E50

Temperature resistance (min.): -30 - 100 °C · Simmering type: A - With rubberized outer part / one sealing lip. · Ø inside: 16 mm · Ø outside: 25 mm · Width: 7 mm · Manufacturer: Puch · Material: NBR · Surface: rubberized

Gasket cylinder base 1.5 mm | Puch

Place of use: Cylinder base · Thickness: 1.5 mm

swiing oil drain plug | Puch ZA50

Manufacturer: swiing · Material: Steel · Surface: galvanized (blue) · Screw head: Hexagon · Drive: External hexagon · Puch OEM number: 321.1.10.670.1

NSK E20 shoulder ball bearing

Bearing type: Deep groove ball bearing · Stock number: E20 · Ø inside: 20 mm · Ø outside: 47 mm · Width: 12 mm · Inner ring width: 12 mm · Manufacturer: NSK · Ball bearing closed: No · Bearing clearance: CN (standard) · Bearing cage: Brass cage ball-guided · Material: Brass · Surface: blank

NSK L17 shoulder ball bearing

Bearing type: Shoulder bearing · Stock number: L17 · Ø inside: 17 mm · Ø outside: 40 mm · Width: 10 mm · Inner ring width: 10 mm · Manufacturer: NSK · Ball bearing closed: No · Bearing clearance: CN (standard) · Bearing cage: Brass cage ball-guided · Material: Brass · Material: Steel · Surface: blank / oiled · Area of application: Standard

Shim 17/24/0.1 Crankshaft L17 Bearing | Puch

Ø inside: 17 mm · Nominal diameter inside: 17 mm · Ø outside: 25 mm · Thickness: 0.1 mm · Manufacturer: Puch · Material: Steel · Surface: blank / oiled

swiing® ingenious clutch springs reinforced (+20%) (Version 2.0) | Puch E50

Spring design: Pressure spring · Ø wire: 1.7 mm · Ø inside: 4.8 mm · Ø outside: 8.3 mm · Total length: 28 mm · Color: blue · Manufacturer: swiing® ingenious parts · Number of components: 3 pcs · Material: Spring steel · Surface: coated · Area of application: Tuning

O-ring oil drain ZA50 small

Place of use: Outlet · Ø inside: 4.2 mm · Ø outside: 9 mm · Cord thickness: 2.4 mm · Color: black · Manufacturer: Puch · Puch OEM number: 900.3797

O-ring oil drain ZA50 large

Place of use: Outlet · Ø inside: 11 mm · Ø outside: 16 mm · Cord thickness: 2.5 mm · Color: black · Manufacturer: Puch · Puch OEM number: 901.3784

Koyo 12.7/17.46/15.8 pinion shaft | Puch ZA50

Manufacturer: Koyo · Bearing type: Needle box · Dimension needle bearing: 12.7/17.5 x 15.7 · Ø outside: 17.5 mm · Width: 15.7 mm · Ø inside: 12.7 mm

swiing® revival gearbox cover gasket | Puch Maxi S LG2 ZA50 engine

Manufacturer: swiing® revival parts · Material: Sealing paper · Color: sand-colored · Number of components: 1 pcs · Total length: 175 mm · Width: 133 mm · Thickness: 0.3 mm · Number of fixing points: 6 pcs

O-ring decoupling shaft Z50 Ø 6 x 1.5 mm

Place of use: Uncoupling shaft · Ø inside: 6 mm · Ø outside: 9 mm · Cord thickness: 1.5 mm · Manufacturer: Puch

swiing® revival thrust washer 12.5/18/2.5 gearbox | Puch Z50

Manufacturer: swiing® revival parts · Material: Steel · Surface: hardened & ground · Ø inside: 12.5 mm · Ø outside: 18 mm · Thickness: 2.5 mm

Jasil crankshaft | Puch 3- & 4-speed models

Manufacturer: Jasil · Total length of crankpin on clutch side: 73 mm · Number of gears: 3 pcs · Number of gears: 4 pcs · Area of application: Standard

Clutch basket 21 teeth kickstarter | Puch E50

swiing® revival nut & washer for clutch (kickstart) | Puch E50

Manufacturer: swiing® revival parts · Material: Steel · Surface: galvanized (blue) · Thread type: MF10x1 (fine pitch thread) · Drive: External hexagon · Height: 5 mm · Width across flats SW: 19 mm · Strength class: 8

Oil seal NBR 22/40/7 AS crankshaft | E50

Place of use: Crankshaft · Temperature resistance (min.): -30 - 100 °C · Simmering type: AS - With rubberized outer casing / one sealing lip / one dust lip. · Ø inside: 22 mm · Ø outside: 40 mm · Width: 7 mm · Manufacturer: Puch · Material: NBR · Surface: rubberized

Oil seal NBR 17/28/7 AS Pinion shaft | Puch Z50

Place of use: Pinion shaft · Temperature resistance (min.): -30 - 100 °C · Simmering type: AS - With rubberized outer casing / one sealing lip / one dust lip. · Ø inside: 17 mm · Ø outside: 28 mm · Width: 7 mm · Manufacturer: Puch · Material: NBR · Surface: rubberized · Area of application: Standard

Starter cable in engine | Puch ZA50

Ø Stranded wire: 1.5 mm · Cable length: 68 mm · Nipple shape: Barrel (transverse) · Ø nipple: 6 mm · Nipple length: 8 mm · Manufacturer: Made in Austria · Puch OEM number: 910.4.18.001.0

Shim 17/25/0.2 Crankshaft L17 Bearing | Puch

Ø inside: 17 mm · Nominal diameter inside: 17 mm · Ø outside: 25 mm · Thickness: 0.2 mm · Manufacturer: Puch · Material: Steel · Surface: blank / oiled

Shim 17/24/0.3 Crankshaft L17 Bearing | Puch

Ø inside: 17 mm · Nominal diameter inside: 17 mm · Ø outside: 24 mm · Thickness: 0.3 mm · Manufacturer: Puch · Material: Steel · Surface: blank / oiled

Surflex clutch 1st gear | Puch ZA50

Manufacturer: Surflex · Material: Composite materials · Material: Steel · Thickness: 12 mm · Recording type: Interlocking · Number of jaws: 3 pcs · Ø inside: 14 mm · Ø inside: 17 mm · Number of springs: 3 pcs · Ø outside: 83.5 mm · Area of application: Original · Area of application: Standard

Jasil connecting rod | Puch

Manufacturer: Jasil · Material: Steel · Surface: copper-coated · Connecting rod length center-center: 90 mm · Total length: 114.5 mm · Ø piston pin (B): 12 mm · Ø Connecting rod bolt: 14 mm · Ø lower connecting rod eye outside: 24.6 mm · Ø upper connecting rod eye outside: 20.9 mm · Ø lower bearing inside: 18 mm · Ø inside upper bearing: 15 mm · Dimension lower bearing: 14/15 x 9.75 mm · Dimension upper bearing: 12/15 x 14.7 mm · Connecting rod pin length: 34 mm · Thickness: 10 mm · Area of application: Standard · Area of application: Tuning

GPO reinforcement plate 1.5 mm clutch (2-/ 3-jaw) Inox | Puch E50

Manufacturer: GPO · Material: Chrome steel (known as Nirosta®) · Ø inside: 40 mm · Ø outside: 90.5 mm · Height: 1.5 mm · Area of application: Road use

swiing® revival gearbox cover gasket ZA50 engine | Puch Maxi S -2A, X30 NG - 2AH

Manufacturer: swiing® revival parts · Material: Sealing paper · Color: sand-colored · Number of components: 1 pcs · Total length: 175 mm · Width: 125 mm · Thickness: 0.3 mm · Number of fixing points: 6 pcs · Puch OEM number: 321.1.10.649.1

Gilardoni italkit diaphragm seal | Puch

Manufacturer: Gilardoni italkit · Material: Sealing paper · Place of use: Admission · Thickness: 0.5 mm · Hole pattern [mm]: 34 x 60 · Area of application: Racing · Area of application: Tuning

swiing® revival exhaust gasket 22 mm 2-piece reinforced | Puch

Manufacturer: swiing® revival parts · Material: Sealing carton · Surface: coated · Place of use: Exhaust · Thickness: 2.15 mm · Ø inside: 26.5 mm · Ø outside: 34 mm

swiing® revival thrust washer 12.5/18/2 gearbox | Puch Z50

Manufacturer: swiing® revival parts · Material: Steel · Surface: hardened & ground · Ø inside: 12.5 mm · Ø outside: 18 mm · Thickness: 2 mm

O-ring selector shaft Z50

Place of use: Shift shaft · Ø inside: 8.3 mm · Ø outside: 13.1 mm · Cord thickness: 2.4 mm · Hardness [Shore]: 70 Shore · Color: black · Manufacturer: Puch · Number of components: 1 pcs · Material: NBR

Clutch hub Z50 engine Occ. | X30 Sport, Velux

Manufacturer: Puch · Recording type: Interlocking · Toothing type: straight toothed · Area of application: Original

swiing® ingenious needle roller bearing 12/15/16.2 "Racing" silver cage

Bearing type: Needle roller and cage assembly · Bearing cage: Silver cage · Dimension needle bearing: 12/15 x 16.2 · Ø inside: 12 mm · Ø outside: 15 mm · Manufacturer: swiing® ingenious parts · Width: 16.2 mm · Tomos OEM number: 035548

Connecting rod bushing 10/12/13 bronze | Puch

Ø inside: 10 mm · Nominal diameter inside: 10 mm · Ø outside: 12 mm · Total height: 13 mm · Manufacturer: Puch · Material: special bearing bronze

Rito Crankshaft Racing | Puch E50

Manufacturer: Rito · Material: Steel · Cheek type: Full cheeks · Crankshaft stroke: 43 mm · Connecting rod length center-center: 90 mm · Total length of crankpin on clutch side: 74 mm · Total length crankpin ignition side: 67 mm · Ø crank webs: 69.9 mm · Ø piston pin (B): 12 mm · Ø Connecting rod eye: 15 mm · Ø Bearing seat (clutch side): 17 mm · Ø Bearing seat (ignition side): 17 mm · Thread type: MF10x1 (fine pitch thread) · Thread length: 11 mm · Thread length: 14 mm · Dimension needle bearing: 12 / 15 x 15 mm (axe 12) · Wide crank webs: 34 mm · Length 1st paragraph: 9 mm · Length 2nd paragraph: 14.5 mm · Length 3rd paragraph: 25 mm · Ø 1st step (on the coupling side): 22 mm · Ø 2nd shoulder (on the clutch side): 17 mm · Ø 3rd step (on the clutch side): 15 mm · Length of shoulder (ignition side): 26.3 mm · Weight: 970 g · Number of gears: 1 pcs · Area of application: Racing · Area of application: Tuning

swiing® revival gasket set engine | Puch Maxi S - 2A (ZA50 engine)

Manufacturer: swiing® revival parts · Number of components: 10 pcs · Hole spacing inlet: 32 - 38 mm · Ø outlet inside: 22 mm · Hole spacing outlet: 42 mm · Hole pattern [mm]: 44 x 44 · Area of application: Standard

swiing® revival thrust washer 12.5/18/1.4 gearbox | Puch Z50

Manufacturer: swiing® revival parts · Material: Steel · Surface: hardened & ground · Ø inside: 12.5 mm · Ø outside: 18 mm · Thickness: 1.4 mm

swiing® revival fitting sleeve engine housing | Puch Z50

Manufacturer: swiing® revival parts · Material: Steel · Surface: galvanized (blue) · Ø outside: 10 mm · Total length: 20 mm

Gearshift engine Occ. | Z50

Manufacturer: Puch · Material: Steel · Surface: raw

GPO screw set for engine mounting, galvanized | Puch

Manufacturer: GPO · Material: Steel · Surface: galvanized (blue) · Area of application: Standard · Thread type: M8x1.25 (standard thread) · Drive: External hexagon · Screw head: Hexagon · Width across flats SW: 13 mm · Thread length: 23.5 mm · Shank: Yes · Strength class: 8.8 · Storage method: Sack · Dimension storage box: 100 x 90 x 10 · Number of components: 12 pcs · Color: silver

HK Clutch "Racing" Kickstarter Aramid | Puch E50

Manufacturer: HK Clutches · Material: Steel · Material addition: Aluminum · Recording type: Cone mounting · Number of jaws: 3 pcs · Number of springs: 3 pcs · Ø inside: 13.6 mm · Ø inside: 14.6 mm · Ø outside: 93 mm · Thickness: 20.3 mm · Area of application: Racing

swiing® revival spring gearshift Inox | Puch Velux

Spring design: Nose feather · Manufacturer: swiing® revival parts · Material: Chrome steel (known as Nirosta®) · Surface: electropolished · Area of application: Standard · Puch OEM number: 320.5.14.018.1

swiing® revival cylinder base gasket 38 mm 0.5 mm | Puch X30 Velux

Manufacturer: swiing® revival parts · Material: Oiled paper · Place of use: Cylinder base · Thickness: 0.5 mm · Ø cylinder: 38 mm

swiing® ingenious spring gearshift (reinforced, +20%) Inox | Puch X30 Z50

Manufacturer: swiing® ingenious parts · Material: Chrome steel (known as Nirosta®)

Clutch bell ZA50 Ø 10.25 mm 13 teeth NOS | Puch

Manufacturer: Puch · Material: Steel · Toothing type: helical toothed · Number of teeth: 13 pcs · Ø Receptacle: 10.25 mm · Area of application: Original

Clutch Surflex Puch Supermaxi E50 (long pads)

GPO screw set for engine mounting Inox | Puch

Manufacturer: GPO · Material: Chrome steel (known as Nirosta®) · Drive: External hexagon · Screw head: Hexagon
